Chapter 8 - Troubleshooting
8-27
DISPLAY
TEST
FAILURE SOLUTIONS
KGS or LBS
Kilograms or pounds.
Default is Lb.
WSVR = 4
Indicates WAVERSAVER that was selected Default is 4.
In Calibration
GRAD
Indicates next parameter will be
None
graduation size.
1 or 2 or 5 etc.
Graduation size calibrated in unit (least
Default is 1.
significant digit on display will change by
this amount).
SPAN
Indicates next parameter will be Span.
None
10000
Span value calibrated in unit.
Default is 10,000.
(example)
ZR CNT
Indicates next parameter will be A to D
counts representing the Zero Count.
--
36780
A to D counts that indicate the calibrated
Default is 36780.
(example)
Zero.
FS CNT
Indicates next parameter will be Full Scale
None
Count. 0 in most significant digit indicate
value >1,000,000.
992000
A to D counts that indicate the Calibrated
Default is 992000.
(example)
Span Value.
SC CAP
Indicates next parameter will be Scale
None
Capacity.
999999
Scale capacity value calibrated in unit.
Default is 10,000.
(example)
0 TOL
Indicates next parameter will be Zero
None
Tolerance.
10
Zero Tolerance value calibrated in unit.
Default is 10.
(example)
AO TOL
Indicates next parameter will be
None
Auto Zero Tolerance
10
Auto Zero Tolerance set during calibration
None
