HI 2151/30WC MANUAL
7-4
(* if ordered)
•
Parallel BCD board, tri-stated. With 6" cable P/N 0551-
0327, model HI2151/20XX-B2. With 24" cable Prt. # 0509-
0389-02, model HI 2151/30XX-B9. With 60" cable Prt. #
0551-0330, model HI2151/30XX-B5.
•
Allen-Bradley RIO. Prt. # 0551-0351, model HI2151/
30XX-B8.
•
PROFIBUS Field Bus Interface. Prt. # 0535-0439, model
HI2151/30XX-B12.
•
DDE I/O Server, Prt. 0551-0419-01, HI2151/30XX-B14
•
Setpoint Option Card Prt. # 0551-0288, model HI2151/
30XX-D2
Option slots are labeled on the top circuit board as follows:
READ PANEL LABEL
26 PIN CONN NUMBER
Option 1
J5
Option 2
J4
Output Option Boards may be ordered and installed into these slots as
follows:
BOARD
QUANTITY
OPTION SLOT
Analog
2
1 and/or 2 (When using only 1 board,
position 1 is preferred due to option
cover compatibility)
BCD
1 only
1
A-B RIO
1 only
1 or 2
PROFIBUS
1 only
1 or 2
NOTE:
You can install either the A_B RIO or the Profibus option but you cannot install both
at the same time.
Set Points
About Set Points
The set point value is the target weight or level. It may be set in either
net, gross, ROC*, Total*, or Peak* hold weight units. When entering
this value, the corresponding LED flag will appear on the display. The
operator may toggle this flag to the desired mode by pressing the
MODE button. Refer to the Set point Limits section following installa-
tion for a description of set point limits.
NOTE:
Only works when the ROC, Total, or Peak options are installed in the controller.
Set Point Limits
Dead Band Limits
The dead band value can be set as a positive or negative value. It is
used to prevent relay chatter once the set point is reached.
