HI 2151/30WC MANUAL
7-18
For example, to set point one to 1000 Lbs gross on instrument number
10, the outgoing command would be as follows:
NOTE:
The example uses decimal and mnemonic abbreviation format for clarity, however,
the actual data would be in ASCII format.
Command
Meaning
C
Allows you to change modes between Net/Gross,
lb/kg, or Hold/Unhold Display.
SUB-CMD
Meaning
M
Toggles between Net and Gross weight mode.
U
Unit (toggles between Lbs. and Kg.)
H
Toggles between display hold and unhold.
Command
Meaning
A
Used to auto tare or auto zero the instrument.
SUB-CMD
Meaning
T
Auto tare the instrument. (Scale must not be in
motion.)
Z
Auto zero the instrument.(Scale must not be in
motion and mode must be set to Gross)
P
Print command. Functionally the same as the print
button on the key board.
The data setup through the format command will be
sent to the port configured as a printer.
Command
Meaning
P1 or P2
Print to either ports 1 or 2.
An optional "subcommand" of up to 37 ASCII characters may be
entered and will be printed before the formatted data.
SUB-CMD
Meaning
37 ASCII characters maximum.
H
The ASCII characters supplied in the subcommand
(maximum of 20 characters) will be printed as a
heading and saved for each subsequent X - transmit
START
CHAR
INSTRUMENT
ADDRESS
CMD
SUB
CMD
CMD
7 BYTE
DATA
D-7 . . . D-1
MODE
CR
2 BYTE CHECKSUM
EOT
CHK-1
CHK-2
>
10
S
S
1
1000
G
CR
CHK-1
CHK-2
EOT
