HI 2151/30WC MANUAL
7-12
NOTE:
The example uses decimal and mnemonic abbreviation format for clarity, however,
the actual data would be in ASCII format. A leading zero (i.e. 01) is required for sin-
gle digit addresses for serial port #2.
4. There is one space (20 hex) required between each type of data fol-
lowing the INSTRUMENT ADDRESS, hence, the outgoing com-
mand represented in hex format would be:
3E
31
30
20
58
20
47
0D
34
44
04
>
1
0
X
G
CR
4
D
EOT
An example using the "x" transmit command without Hardy Link
is:
Serial Commands,
Command Set
The checksum is computed by totaling the bytes in the command
stream starting with the INSTRUMENT ADDRESS through (and
including) the CR and then subtract 256 from the total until the remain-
der is less than 256 (to achieve a one byte maximum). The result is then
represented as two ASCII bytes and appended to the command, fol-
lowed by an EOT (04).
Value
Description
31
address - instrument number 10 - ASCII "1"
30
address - instrument number 10 - ASCII "0"
20
space
58
X
20
space
47
G
0D
CR
---------------
=
14d
Value
Description
-
100
---------------
=
4d
Serial commands are transmitted from the instrument back to the host
in the format they were received from the host with the return data (and
units) added to the message and an LF added to the CR.
Using the above example, the return data would be:
START
CHAR
CMD
SUB-CMD
CR
2 BYTE CHECKSUM
EOT
CHK-1
CHK-2
>
X
G
CR
CHK-1
CHK-2
EOT
