Cub Cadet 4 x 2 Big Country - Poly Bed & Steel Bed - Manual (Page 42)

Poly Bed 4 X 2 Drive System
38
Table 2: Transaxle Torque
Note 1: Apply releasable thread-locking compound
such as Loctite 242.
Note 2: The cable attachment arm should be 90
degrees rearward from the shift arm within the tran-
saxle.
Note 3: Confirm proper return action from he torsion
spring.
Item Torque Note
Ring gear to differen-
tial housing 22 ft-lb
29 N-m 1
Differential lock shift-
arm stop bolt 87 in-lb
9.8 N-m
Differential lock shift-
arm mounting nut 78 in-lb
8.8 N-m 2
3
Transaxle housing
bolts 78 in-lb
8.8 N-m
Axle tube to tran-
saxle housing 18 ft-lb
25 N-m
Detent bolt 27 ft-lb
37 N-m
Safety switch 87 in-lb
9.8 N-m
diff. lock cable
bracket 78 in-lb
8.8 N-m
shifter cable bracket 18 ft-lb
25 N-m
Axle nut (castle nut) 110 ft-lb
145 N-m
lug nuts 25 ft-lb
34 N-m
Brake backing plate
bolts 25 ft-lb
34 N-m
