5-27
INSTRUMENT CLUSTER TEST PROCEDURES
(Nothing on cluster works but rest of vehicle ok)
STEP DETAILS
Remove instrument cluster. Gently and carefully pry cluster from dash.
Unplug connector. From back of cluster.
Check for power to cluster.
Note: Pin locations are numbered on back
of plug.
Check wiring to cluster.
Set park brake. Turn ignition switch to an on
position. Check voltage from red wire (pin 5) to
green wire (pin 12). Should be 12 volts. See
Figure 5-17.
If voltage present, plug connector back into
cluster and use a paper clip or small stiff wire
to jump from pin 23 to pin 12 at back of
connector. Green “on” light should illuminate.
See Figure 5-18.
If illuminates, controller is most likely at fault.
If does not illuminate, replace instrument
cluster.
If no voltage present, check continuity of wires
to controller.
Instrument Cluster Large Twist Lock
Connector Controller Connector
Red wire (pin 5) to pin 50
Green wire (pin 12) to pin 51
If no continuity on either wire, repair or replace
wire harness as needed.
If continuity on both wires, replace controller.
