Cub Cadet Fun Runner - Manual (Page 112)

6-12
PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION
Pin 35
High Pin 24
to
Pin 34
Low Pin 15
to
Pin 42
Charge Pin 20
to
Pin 45
Park Pin 8
to
Pin 57
Lights Pin 7
to
Pin 49
If no continuity, repair or replace wire
harness as needed.
If continuity ok, replace controller only
when you are sure that the signal to
trigger or activate the indicator is
working properly.
Head and tail lights not
working. Bad switch.
Broken wire.
Turn ignition switch to a run position
and check voltage on hazard light
switch. It should be 6 volts with lights
off and 0
volts when on. If voltage present and
does not drop to 0 volts when switch is
on, replace switch.
If no voltage at switch, check continuity
of switch wires to large controller twist
lock connector.
Orange switch wire to pin 41
Green switch wire to pin 38
If no continuity on either wire, repair or
replace wiring harness as needed.
If continuity is good on both wires,
