Problem possible causes corrective action – Cub Cadet Fun Runner User Manual
Page 111

6-11
PROBLEM
POSSIBLE CAUSES
CORRECTIVE ACTION
Faulty wire.
Faulty controller
Pin 19
On light
Pin 23
High light
Pin 24
Low light
Pin 15
Charge light
Pin 20
Park light
Pin 8
Headlight
Pin 7
When jumped, the indicator should
illuminate. If no illumination, replace
instrument cluster. If illumination, check
continuity of wire to controller.
Unplug connector from instrument
cluster and check continuity to large
twist lock connector at controller for the
indicator being tested.
Instrument Cluster Large Twist Lock
Plug Controller Plug
Fault Pin 14
to
Pin 43
Temp Pin 18
to
Pin 47
Batt Pin 21
to
Pin 36
Rev Pin 19
to
Pin 46
On Pin 23
to
