Disconnect batteries (Figure 4-35).
Warning:
Batteries are probably charged and “hot”.
Use care to not short cables to frame or
other battery terminals.
Disconnect cables going from battery to battery
first.
Loosen wing nuts and slide connectors off.
Disconnect cables from battery to controller
last.
Remove hold down bars. Two bars, one over front 3 batteries and one
over rear battery. Be careful not to short bars
across batteries.
Remove batteries (Figure 4-36). Do not let battery terminals short to frame.
Place insulation over all battery terminals if
necessary to prevent shorting (electrical tape if
nothing better available).
Check fuse. If damage to fuse is suspected.
In the event the fuse is damaged, find the
cause before reconnecting batteries.
Replace batteries. Be sure rear battery positive terminal is toward
the right side, right front battery positive
terminal is on front of battery, and positive
terminals on other two on the rear of those
batteries (See Figure 2-2 in Section 2).
Replace hold down bars (Figure 4-37). Long bar between terminals, side to side,
across three front batteries and the short bar
across the rear battery.
Reconnect battery cables (Figure 4-38). Connect fused cable to positive terminal on left
front battery.
Connect other controller power cable from
master switch to negative terminal on rear
battery.
Connect rest of battery terminals in series
(positive on one battery to negative on the
next) (See Figure 2-2 in Section 2).
Connect charger cable (Figure 4-39). To receptacle in front of rear body section.
