Brookfield Engineering Labs., Inc. Page 12 Manual No. M03-165-F0612
SELECT SPINDLE
Initiates spindle selection on the first press and then selects the currently scrolled-to
spindle when pressed a second time.
PRINT
Selects printing and non-printing modes when a printer is attached.
OPTIONS/TAB
OPTIONS: Presents the Options menu, flashing the last escaped option.
TAB: Toggles between selectable items when indicated, as shown in Figure
I-2.
f
g
°F(FAHRENHEIT) $
f
g CGS UNITS #
Note: Symbol indicating
the OPTIONS/TAB key
Figure I-2
Note: Inverted text (black background with white lettering) indicates that the information
is flashing on the viscometer display.
I.7 Cleaning
Make sure the instrument is in a decent working environment (dust-free, moderate temperature,
low humidity, etc.).
Make sure the instrument is on a level surface.
Hands/fingers must be clean and free of residue sample. Not doing so may result in deposit
build up on the upper part of the shaft and cause interference between the shaft and the pivot
cup.
Be sure to remove the spindle from the instrument prior to cleaning. Note left-handed thread.
Severe instrument damage may result if the spindle is cleaned in place.
Instrument and Keypad: Clean with a dry, non-abrasive cloth. Do not use solvents
or cleaners.
Immersed Components (spindles): Spindles are made of stainless steel. Clean with a
non-abrasive cloth and solvent appropriate for sample
material.
When cleaning, do not apply excessive force, which may result in bending spindles.
OPTIONS
TAB
PRINT
SELECT
SPINDLE
