Module OEM Implementation Manual Section 4 - Host/Module Communications
Welch Allyn OEM Technologies Confidential Page 45
Host Command/Module Response Overview Table
Command Command Description Response Response Description
Enter standby mode Acknowledge with Module status
Enter measurement mode Acknowledge with Module status
Enter auto run mode Acknowledge with Module status
(Invoked with enter measurement
or auto run mode command) CO
2
waveform data packets sent at
programmed interval
(Invoked with enter measurement
or auto run mode command) Breath data packets sent at pro-
grammed interval
Request Module status Acknowledge with Module status
Sample Zero Reference Gas Status 25 = Cal in Progress
Sample Span Reference Gas Status 25 = Cal in Progress
Perform Zero Calibration Status 25 = Cal in Progress
Abort Calibration Status 00, ok (operation aborted)
Calibration not in Progress
Request software version dyyyy> Version # with month, day, year sent
Request hardware version Hardware version # sent
Request ambient barometric
pressure Ambient barometric pressure sent
Request sensor temperature Sensor temperature sent
Request single CO
2
packet CO
2
measurement sent
Request single breath data
packet Breath data packet sent
Request current pump flow rate Current pump flow rate sent
Request sensor EEPROM revi-
sion # Revision # sent
Request customer code Sensor customer code sent
Request sensor serial # Sensor serial # sent
Request last calibration date dyyyy> Last calibration date sent
Software reset No response
Specify breath data timeout Data field echoed
Specify pump flow rate Command echoed
Update Span Gas Status 24 = Cal Ready for Next Step
dyyyy> Update Calibration Date. Status 24 = Cal Ready for Next Step
Specify CO
2
waveform data
packet interval
Data field echoed
Specify breath data packet inter-
val Data field echoed
Specify measurement compen-
sation ON or OFF, SW reset New and previous measurement
compensation settings echoed
