118
Property Browser of Atomic Structure Diagram
Atomic Structure Diagram after Modification of Properties
You can change the number of protons and electrons in each layer in the detailed setting.
When you click the button, the Atom Set box pops up. To change the atomic number,
change the number in the “Nuclear” setting. Changing this number will not automatically
change the rest of the diagram. To change the number of shells shown, change the number
in the “Extranuclear” setting. If there aren’t electrons in the shell, you must select zero.
Details of Atom Set box
Atomic Structure Diagram after Modification of Properties
Chemical Equipment
When you click the Chemical Equipment Button , the sub-toolbar is pops up, which
provides images of various types of equipment used in chemical experiments—balance,
weight, alcohol lamp, flame, thermometer, and others.
