Page 35: Optional device connections
Model 2090 Multi-Device Controller
OPTIONAL DEVICE CONNECTIONS
NC C NO
NC C NO
NC C NO
SW 1
SW 2
SW 3
SW 4
Auxiliary devices use a single-pole, double-throw RF relay to
control simple on/off operation. The connection type is SMA.
Additional devices (for example: CMU, Analyzers, dual
polarized horn antennas, etc.).
©ETS-Lindgren, April 2006
35
Revision G– P#399199
