ETS-Lindgren 2090 Controller - Manual (Page 161)

Model 2090 Multi-Device Controller
E003 p
his error indicates that the device is still moving
his error is more often caused by excessive overshoot
rshoot may be an indication of an
Device Will Not Sto
T
several seconds after the motor has been deactivated. If
this error occurs and the device continues moving under
its own power, remove power from the device
immediately and contact ETS-Lindgren for service.
T
of a device. Such ove
overloaded device or the failure or degradation of the
motor brake for devices so equipped. An example of
such a case would be a tower for which the cross boom
carrier continues moving in the down direction after
device motion has been stopped.
This error may also occur in conjunction with an
E002
or an E005 , being reported after the previous error is
cleared. This is simply a side effect of the other error
condition preventing the Model 2090 from detecting the
motor stopping.
E004 evice Moving In the Wrong Direction
This error indicates that the device has moved too far in
the direction opposite the direction commanded. On
towers, this error can be caused due to an overloaded
cross boom, or a weak brake, where the carrier moves
down under the force of gravity before moving up. For
devices with split-phase motors (towers and light duty
turntables) this error can also be caused by reducing the
reverse delay (
P8 ) below an acceptable value. Split
hase motors must come to a complete stop before
reversing directions.
move in
e wrong direction! In the case of a mis-wiring at
installation, the limit switches (if so equipped) should
also be checked to verify they are wired correctly.) In
addition, heavy-duty devices using three-phase motors
will reverse direction if any phase of the power is
switched. Thus, chan
D
p
On a new installation, there is the possibility that the
device was mis-wired at the time of installation,
especially for assemblies where the control and motor
portion are shipped disassembled. For these cases, note
that this error will be generated if either the motor or the
encoder are mis-wired. (If both are mis-wired, the error
will not be generated but the device will always
th
ges in facility wiring can also
