Appendix A: Model 2090 GPIB Command Reference Model 2090 Multi-Device Controller
WL
Compatibility:
Devices:
+
Necessary for negative values
Decimal nalue for the clockwise limit to be set in
degrees.
CALL ibwrt (TableUD%, "WL 359.9")
1090, 2090
Description: Changes the clockwise limit of the device. The specified value must be
greater than the counterclockwise limit and between -999.9 and 999.9. If in
N1 mode any decimal is ignored and rounded to the nearest integer. NOTE:
Unlike editing from the front panel, the 2090 allows setting the limit above
the current position from the GPIB.
Turntables
Syntax: WL [+/-] XXX[.X]
Optional for positive values
-
XXX[.X]
In N1 mode .X is ignored
In N2 mode .X is optional.
Leading zeros are optional.
Example: CALL ibwrt (TableUD%, "WL 90") ' Change CW limit of the
' turntable to 90 degrees.
' Change CW limit of the
' turntable to 359.9 degrees.
See Also: WL 1050/1060, WL?
WL?
Compatibility: 1090, 2090
Queries the turntable's clockwise limit. The value returned is either in N1
(XXX) or N2 (XXX.X) format depending upon the current numeric mode.
Negative values are preceded by a "-" minus sign.
Syntax:
Description:
Devices: Turntables
WL?
Response: [-]XXX[.X] Value of the clockwise limit setting in degrees.
Example: CALL ibwrt (TableUD%, "WL?") ' Query turntable clockwise
' limit
CALL ibrd (TableUD%, rdbuf$) ' Read response
See Also: WL 1050/1060, WL 1090/2090
ZERO
Compatibility: 2090 (Firmware Rev 3.00)
Description: Initiates a zero reference scan for devices equipped with absolute zero
reference pulses. See the
ZERO parameter setting for more information.
Devices: Towers, Turntables
Syntax: ZERO
Example: CALL ibwrt (TableUD%, "ZERO") ' Initiate zero scan
See Also: ZERO?
