Connecting the
analogue
components
To enhance your system, you can connect
optional components. Analogue sound from
the connected component is recorded as an
analogue signal on the MD.
Refer to the operating instructions of each
component.
Connecting the audio cords (not
supplied)
when using audio cords (not supplied) to
connect other AV components to the system,
make sure to insert the plugs firmly, pushing
them in all the way. No sound will be
produced if the plugs are not inserted
securely.
Not pushed in all the way
]ldSIl**>= N.G.
Connect to VIDEO input
jack
OK
Insert completely
to the audio output jack of
a component
Tip
The system does not support Dolby Pro Logic, so
you cannot listen to material played back on a DVD
player with Dolby Digital or Dolby Pro Logic. In
addition, this system cannot make a digital
recording from a disc that was recorded with Dolby
Digital.
* DOLBY, the double-D symbol □□, the Dolby
Digital and "PRO LOGIC" are trademarks of
Dolby Laboratories Licensing Corporation.
78
