Factory Repair Parts A-11
System Board Assemblies (Continued)
System
board,
150-MHz PWA,PLN,LXPiCD-150ST,
NBK
I/O interface
cable CBL,I/O TO M/B,LXPiCD A-7
Bracket, I/O BRKT,I/O,LXPi
Serial EMI
clip, I/O CLP,EMI,SER,I/O,XPiCD
Docking
EMI clip, I/O CLP,EMI,DOCK,I/O,XPiCD
Diskette, field
service DSK,FLD SERV,F3,US, LXP
Technical booklet,
service DOC,SERV,GUIDE,LXPi
Trackball
Optical trackball assembly SVC,ASSY,TBALL/SWT,
LXPi+CD 4-11
Trackball interface
cable CBL,TBALL,LXPi+CD 4-11
Trackball
subassembly SUBASSY,TBALL,OPTICAL,
LXPiCD
Trackball
board PWA,TBALL,OPTICAL,
LXPiCD A-2
Trackball TBALL,OPTICAL,LXPiCD A-2
Trackball
button board SUBASSY,TBALL,SWT BD,
LXPiCD A-2
Technical booklet DOC,SERV,GUIDE,LXPi
Table A-1. Factory Repair Parts and Assemblies (Continued)
Part or Assembly Name Order Name Figure
