Removing and Replacing Parts 4-1
Chapter 4
Removing and Replacing Parts
T
his chapter provides instructions for removing and replacing field-
replaceable components, assemblies, and subassemblies. For removal and
replacement procedures for factory-replaceable parts, see Appendix A,
“Factory Repair Parts.”
Unless otherwise noted, each procedure in this chapter assumes the following:
• The computer and any attached peripherals are turned off, and the peripher-
als are disconnected from the I/O panel on the back of the computer.
• A part can be replaced by performing the removal procedure in reverse
order.
When the display assembly is open nearly 180 degrees, use a book or something
similar to support the display assembly. The angle of the display assembly with
respect to the bottom case should never be allowed to exceed 180 degrees. Also,
when performing the procedures in this chapter, the locations or directions rela-
tive to the computer are as shown in Figure 4-1 unless otherwise specified.
Figure 4-1. Computer Orientation
right side left side
back of computer
front of computer
