Removing and Replacing Parts 4-21
Display Assembly Latch and Latch Spring
Figure 4-16. Display Assembly Latch and Latch Spring Removal
To remove the display assembly latch and latch spring, follow these steps:
1. Remove the display assembly bezel.
2. Turn the display assembly bezel upside down on the work surface.
3. While holding down the display-assembly latch spring, slide the latch
against the spring, rotate the latch upward, and lift the latch and spring
out of the bezel.
Part or Assembly Name Order Name
Display assembly latch LTCH,LXPiCD
Display assembly latch spring SPR,LTCH,LXPiCD
latch
latch spring
display assembly
bezel
