Dell Latitude Xpi CD - Manual (Page 46)

4-8 Dell Latitude XPi CD Service Manual
Memory Compartment Cover
Figure 4-7. Memory Compartment Cover Removal
To remove the memory compartment cover, follow these steps:
1. Turn the computer upside down on the work surface.
2. To release the memory compartment cover, press down on the identa-
tion in the edge of the cover, and then slide the cover towards the edge
of the computer.
Part or Assembly Name Order Name
Memory compartment cover CVR,MEM,LXPiCD
CAUTION: Make sure the work surface is clean to prevent scratching
the computer cover.
memory compartment
cover
