A-6 Dell Latitude XPi CD Service Manual
LCD Assemblies (Continued)
LCD/LED/inverter board
cable, service kit, active-
matrix color, TFT SVGA
display SVC,CBLS,LCD,TFT,SAM-
SUNG,LXPi+CD
Display-assembly
interface cable CBL,FPC,LED/INVRTR,TFT,
12.1” 4-20
Display-assembly
interface cable bob-
bin, 12.1-inch BBN,LCD,TFT,12.1” 4-20
Technical booklet DOC,SERV,GDE,XPi
Bezel service kit, 12.1-inch SVC,BZL,LCD,TFT,LXPiCD 4-15
Display assembly bezel
12.1-inch ASSY,LCD,BZL,12.1” 4-15
Display-assembly latch
spring SPR,LTCH 4-16
Technical booklet DOC,SERV,GUIDE,LXPi
Display case service kit,
12.1-inch SVC,CVR,BK,TFT,LXPi+
Display assembly case,
12.1-inch ASSY,LCD,CVR,BK,TFT,12.1” 4-17
Technical booklet DOC,SERV,GUIDE,LXPi
Display assembly latch ser-
vice kit, 12.1-inch SVC,LTCH,DIS,TFT,LXPi+
Display assembly latch,
12.1-inch LTCH,LCD,STN/TFT,LXP 4-16
Display-assembly latch
spring, 12.1-inch SPR,LTCH 4-16
Technical booklet DOC,SERV,GUIDE,LXPi
Table A-1. Factory Repair Parts and Assemblies (Continued)
Part or Assembly Name Order Name Figure
