A-4 Dell Latitude XPi CD Service Manual
Diskette Drive Assembly (Continued)
Diskette/CD-ROM drive
assembly SUBASSY,FD/CD,LXPiCD 4-23
Diskette/CD-ROM bracket BRKT,FD,AL,RT,LXPiCD 4-23
Hard-Disk Drive Assemblies
Hard-disk drive assembly CUS,HD, xxxxx,yy,MM,zzz,
LXP
*
4-6
Hard-disk drive,
subassembly SUBASSY,HD,xxxxx,yy,MM,
zzz,LXP
*
Hard-disk
drive HD,xxxxx,yy,MM,zzz,REV2 *
Hard-disk
drive bracket BRKT,HD,LXP
Hard-disk
drive mount-
ing screws SCR,M3X4,BIND/PHH,BL
OXIDE
Hard-disk
drive
insulator INSUL,yyMM,LXP *
Technical booklet TSH,HD,LXP
Keyboards
Keyboard assembly,
Belgium KYBD,86,BEL,ALPS,LXPi+ 4-5
Keyboard assembly, China KYBD,85,CHINA,ALPS,
LXPi+ 4-5
Keyboard assembly,
domestic SVC,KYBD,85,DOM,LXPi+ 4-5
Keyboard assembly, Danish KYBD,86,DEN,ALPS,LXPi+ 4-5
Keyboard assembly, French KYBD,86,FR,ALPS,LXPi+ 4-5
* Substitute your drive capacity for xxxxx, your drive height for yy, and the
manufacturer for zzz.
Table A-1. Factory Repair Parts and Assemblies (Continued)
Part or Assembly Name Order Name Figure
