Dell Latitude Xpi CD - Manual (Page 91)

Factory Repair Parts A-9
Miscellaneous Parts (Continued)
Keel plate ASSY,PLT,KEEL,LXPiCD A-12
Deck buoy ASSY,CLMP,THRM,LXPiCD 4-24
Microphone insulator
bracket INSUL,PLSTC,MIPHN/
SWT,LXPiCD
Bottom case assembly CVR,BTM,BLK,LXPi 4-22
Power button BTN,PWR SWT,LXP A-11
Power-button mounting
bracket GDE,PWR SWT,PLSTC,LXPi A-11
Memory compartment
cover CVR,MEM,LXPi+CD 4-5
Palmrest Assembly
Palmrest service kit SVC,ASSY,PLMRST,
LXPi+CD
Palmrest assembly SUBASSY,PLMRST,LXPi+CD 4-9
Technical booklet DOC,SERV,GUIDE,LXPiCD
Screws
Screws service kit SVC,SCR,LXP
3 mm, black SCR,2mmX3mm,PHH,MS,
BLO,LXP B2
3 mm, gold SCR,2mmX3mm,PHH,MS,
NON,LXP B8
4 mm, black SCR,2.6mmX4mm,PHH,MS,
BLO,LXPB7
5 mm, black SCR,2.6mmX5mm,PHH,MS,
BLO,LXPB3
5 mm, gold SCR,2.6mmX5mm,PHH,MS,
NON,LXP B8
Table A-1. Factory Repair Parts and Assemblies (Continued)
Part or Assembly Name Order Name Figure
