Installing a Non-Redundant Power Supply
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is
not covered by your warranty. Read and follow the safety instructions that
came with the product.
1 Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
1 Open the system. See "Opening the System" on page 82.
2 Place the power supply on the chassis. See Figure 3-11. Tighten the screw
to secure the power supply to the chassis.
3 Connect all the power cables to the system board, hard drive(s), and
optical drive.
4 Replace the system cover. See "Closing the System" on page 83.
5 Connect the power cable to the power supply and plug the cable into a
power outlet.
Expansion Card and Expansion-Card Riser
Expansion Card Installation Guidelines
Your system supports one x16 Gen2 PCIe expansion card installed in the slot 1
connector on the expansion-card riser.
CAUTION: Expansion card can only be installed in the slots on the expansion-
card riser. Do not attempt to install expansion cards directly into the riser
connector on the system board.
• The expansion slot supports full-height, half-length cards.
• The expansion-card slot is not hot-swappable.
• PCI Express Generation 2 expansion card is supported in the slot.
CAUTION: To ensure proper cooling, only one of the two expansion cards can
have a power consumption of greater than 15 W (up to 25 W maximum), not
including the integrated storage controller.
