Installing System Components 145
1 Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
2 Open the system. See "Opening the System" on page 82.
3 If applicable, remove the front bezel. See "Removing the Front Bezel" on
page 81.
4 Remove the system board shroud. See "Removing the System Board
Shroud" on page 109.
5 Remove the memory modules. See "Removing Memory Modules" on
page 126.
6 Remove the expansion card and the integrated storage controller card. See
"Removing an Expansion Card" on page 100 and "Removing the Integrated
Storage Controller Card" on page 103.
7 Remove the expansion-card riser. See "Removing an Expansion-Card
Riser" on page 105.
8 Remove the heat sinks and processors. See "Removing a Processor" on
page 127.
9 If applicable, remove the optional iDRAC6 Enterprise card. See "iDRAC6
Enterprise Card (Optional)" on page 114.
10 If installed, remove the optional iDRAC6 Express card. See "iDRAC6
Express Card (Optional)" on page 112.
11 Disconnect all cables from the system board.
12 Remove the nine screws securing the system board to the chassis and then
slide the system board assembly toward the front end of the chassis.
CAUTION: Do not lift the system board assembly by grasping a memory module,
processor, or other components.
13 Grasp the system board assembly by its edges and lift the assembly away
from the chassis. See Figure 3-32.
