112 Installing System Components
Installing the Power Distribution Board Shroud
1 Align the power distribution board shroud using center of the numbered
fan bays 5 and 6 as a guide. See Figure 3-17.
2 Push the shroud down until it is aligned with the system chassis wall.
3 Close the system. See "Closing the System" on page 83.
iDRAC6 Express Card (Optional)
Removing an iDRAC6 Express Card
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is
not covered by your warranty. Read and follow the safety instructions that
came with the product.
1 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2 Open the system. See "Opening the System" on page 82.
3 Pull back slightly on the retention standoff tab at the front edge
of the card and gently lift the card off the retention standoff.
See Figure 3-18.
As the holder releases from the standoff, the connector under the card
disengages from the system board connector.
4 Angle the card so that the notch on the card slips through the clip on the
system board to remove the iDRAC6 Express card.
5 Close the system. See "Closing the System" on page 83.
6 Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
