Using the System Setup Program and UEFI Boot Manager
Option
Description
System Time
Sets the time on the system's internal clock.
System Date
Sets the date on the system's internal calendar.
Memory Settings
Displays information related to installed memory. See "Memory
Processor Settings Displays information related to processors (speed, cache size,
and so on). See "Processor Settings Screen" on page 61.
SATA Settings
Displays a screen to enable or disable the integrated SATA
controller and ports. See "SATA Settings Screen" on page 63.
Boot Settings
Displays a screen to specify the boot mode (BIOS or UEFI).
For BIOS boot mode, you can also specify the boot devices.
See "Boot Settings Screen" on page 63.
Integrated Devices Displays a screen to enable or disable integrated device
controllers and ports, and to specify related features and options.
See "Integrated Devices Screen" on page 64.
PCI IRQ
Assignment
Displays a screen to change the IRQ assigned to each of the
integrated devices on the PCI bus, and any installed expansion
card that requires an IRQ. See "PCI IRQ Assignments Screen" on
Serial
Communication
(Off default)
Displays a screen to enable or disable the serial ports and specify
related features and options. See "Serial Communication Screen"
Embedded Server
Management
Displays a screen to configure the front-panel LCD options and
to set a user-defined LCD string. See "Embedded Server
Management Screen" on page 66.
Power
Management
Enables you to manage power usage of the processor(s), fans,
and memory modules with preconfigured or customized
settings. See "Power Management Screen" on page 67.
System Security
Displays a screen to configure the system password and setup
password features. See "System Security Screen" on page 68,
"Using the System Password" on page 73, and "Using the Setup
Password" on page 75 for more information.
Keyboard
NumLock
(
On default)
Determines whether your system starts up with the NumLock
mode activated on 101- or 102-key keyboards (does not apply to
84-key keyboards).
