Installing System Components 83
Figure 3-3. Opening and Closing the System
Closing the System
1 Place the cover onto the chassis and offset it slightly towards the back of
the system till it snaps in position. See Figure 3-3.
2 Slide the cover towards the front of the chassis till it snaps in position.
3 Rotate the latch release lock in a clockwise direction to secure the cover.
4 Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
1 latch release lock 2 indent
2
1
