Installing System Components 103
Integrated Storage Controller Card
Your system includes a dedicated expansion-card slot on the expansion-card
riser for an integrated SAS or PERC controller card that provides the
integrated storage subsystem for your system’s internal hard drives. The
controller supports SAS and SATA hard drives and also enables you to set up
the hard drives in RAID configurations as supported by the version of the
storage controller included with your system.
Removing the Integrated Storage Controller Card
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is
not covered by your warranty. Read and follow the safety instructions that
came with the product.
1 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2 Open the system. See "Opening the System" on page 82.
3 If applicable, remove the expansion card. See "Integrated Storage
Controller Card" on page 103.
4 Pull the blue release lever to free the card from the connector on the
expansion-card riser.
5 Lift to remove the card.
