10-58
Cisco Catalyst Blade Switch 3130 and 3032 for Dell Software Configuration Guide
OL-13270-03
Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Configuring IEEE 802.1x Authentication
Step 3 aaa new-model Enables AAA.
Step 4 aaa authorization network default group
radius Sets the authorization method to local. To remove the
authorization method, use the no aaa authorization network
default group radius command.
Step 5 radius-server vsa send authentication Configure the radius vsa send authentication.
Step 6 interface interface-id Specify the port to be configured, and enter interface
configuration mode.
Step 7 ip access-group acl-id in Configure the default ACL on the port in the input direction.
Note The acl-id is an access list name or number.
Step 8 show running-config interface interface-id Verify your configuration.
Step 9 copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
