Power-Up and Boot Procedures
CSMIM-T1 Hardware Installation Guide 5-5
5.2.1.1 Normal Mode Error-Free Sequence
Table 5-2 summarizes the LED display states during error-free power-up
in normal mode. The following subsections describe these states.
Table 5-2 Normal Mode Error-Free LED States
Key:
●
On continuously.
✕
Off.
■
Flashing irregularly.
◆
Flashing regularly (about 1Hz).
Activity N1: Testing LEDs
All front panel LEDs light for a few seconds, then all but the Ethernet
LED (segment indicator) turn off, confirming that all LEDs are
operational.
Activity N2: Testing the Hardware
During the power-up sequence, the CSMIM-T1 runs a series of self-test
diagnostics. These diagnostics test internal hardware functions. If a test
fails, the ATTN and STAT LEDs flash and an error message is displayed
on the console port. The TRAF indicator flashes during the power-up
self-tests. After the self-tests complete, only the STAT and Ethernet
channel indicator remain on.
Activity
STAT
Green ATTN
Amber TRAF
Green
N1: LEDs OK ● ● ●
N2: Hardware OK ● ✕ ●
