Chapter 2: INSTALLING THE CSMIM-T1
2-8 CSMIM-T1 Hardware Installation Guide
To put the CSMIM-T1 into ROM Monitor mode, press the SET UP button
within 30 seconds of powering up. You can also reset and set up the
CSMIM-T1 by pressing the SET UP button until the TRAF LED comes
ON, release the button and then press it again. This will reboot the
module, and it will come up into ROM Monitor mode.
2.5.2 Connecting a T1 Network Interface
The T1 Network Interface is used to connect the CSMIM-T1 to the T1
line. The T1 Network Interface port is located on the front panel of the
CSMIM-T1.
To connect to the T-1 network, simply plug the RJ48C connector located
on the T1 Network Interface Cable into the T1 Network Interface port
located on the front panel of the CSMIM-T1.
When the connector clicks into place, the connection is secure. Appendix
A describes the T1 Network Interface port’s signal/pin allocation.
NOTES
The CSMIM-T1 takes approximately 3 minutes to boot in the
ROM Monitor mode, depending on network traffic.
During the boot process, the TEST LED remains on.
The red ATTN light is ON when the unit is in ROM Monitor
state.
