Chapter 6: Modem Guide
6-24 CSMIM-T1 Hardware Installation Guide
Table 6-10 ATV0W2 Report Modulation Speed
1 Not Supported in synchronous mode
2 In synchronous mode or when \V0 is set , the following numeric codes display:
14400 bps=34; 12000 bps = 44; 7200 bps = 40.
ATV0W2 Report Modulation Speed
Modulation Speed
(bps) \V0
\V1 non-rel \V2
non-rel \V4
non-rel \V5
non-rel \V1 rel
\V2rel \V3 \V4 rel
\V5 rel
V.21 or Bell 103 300 1 1 20 1 1 20
V.23 half-duplex 1200 5 1 — 5 1 —
V.22 600 9 1 21 5 1 21
V.22 or Bell 212A 1200 5 22 5 22
V.34/V.22bis 2400 10 23 10 23
V.34/V.32 4800 30 31 11 31
V.34/V.32bis 7200 40 2 33 24 41
V.34/V.32 9600 32 33 12 33
V.34/V.32bis 12,000 44 2 33 25 45
V.34/V.32bis 14,400 34 2 35 13 35
V.34/V.FC 14,400 34 2 35 13 35
V.34/V.FC 16,800 60 61 13 61
V.34/V.FC 19,200 36 37 14 37
V.34/V.FC 21,600 62 63 13 63
V.34/V.FC 24,000 64 65 13 65
V.34/V.FC 26,400 66 67 13 67
V.34/V.FC 28,800 68 69 13 69
