Chapter 6: Modem Guide
6-22
CSMIM-T1 Hardware Installation Guide
Table 6-8
Long Form Connect Result Codes
1
If \V2 or \V4 is set and a reliable link is established, the message displays as
one of the following formats: CONNECT
2
In non-reliable V.21 or Bell 103 connections, the message displays as
CONNECT.
3
Not supported in synchronous mode.
ATV1-M0W2
Report Modulation Speed
Modulation
Speed (bps) Non-rel
\V0 rel
\V1 rel
\V2 rel
1
\V3 rel
\V4 rel
1
\V5 rel
4
V.21
300
—
2&3
V.21/REL
V.21/REL
Bell 103
300
—
2
103/REL
103/REL
V.23 half-duplex
1200
V.23 HDX
3
—
—
V.22
600
3
600
600/REL
600/REL
V.22 \Bell 212A
1200
1200
1200/REL
1200/REL
V.34/V.22bis
2400
2400
2400/REL
2400/REL
V.34/V.32
4800
4800
9600/REL
4800/REL
V.34/V.32bis
7200
7200
9600/REL
7200/REL
V.34/V.32
9600
9600
9600/REL
9600/REL
V.34/V.32bis
12,000
12,000
9600/REL
12000/REL
V.34/V.32bis
14,400
14,400
14,400/REL
14,400/REL
V.34/V.FC
14,400
14,400
14,400/REL
14,400/REL
V.34/V.FC
16,800
16,800
16,800/REL
16,800/REL
V.34/V.FC
19,200
19,200
19,200/REL
19,200/REL
V.34/V.FC
21,600
21,600
21,600/REL
21,600/REL
V.34/V.FC
24,000
24,000
24,000/REL
24,000/REL
V.34/V.FC
26,400
26,400
26,400/REL
26,400/REL
V.34/V.FC
28,800
28,800
28,800/REL
28,800/REL
