Modulation Protocols

CSMIM-T1 Hardware Installation Guide

6-11

6.4.2

Speed and Protocol Connection Matrices

The following tables show the possible speed and protocol combinations
for modem connections. They also illustrate the action of an answer
modem set to use multi-mode answering.

V.34/V.32bis (14400 bps)

at 14400 bps

%B14400

V.34/V.FC (14400 bps)

at 14400 bps

%BV14400

V.34/V.FC (16800 bps)

at 16800 bps

%B16800

V.34/V.FC (19200 bps)

at 19200 bps

%B19200

V.34/V.FC (21600 bps)

at 21600 bps

%B21600

V.34/V.FC (24000 bps)

at 24000 bps

%B24000

V.34/V.FC (26400 bps)

at 26400 bps

%B26400

V.34/V.FC (28800 bps)

at 28800 bps

%B28800

NOTE

For the highest possible throughput available, set the
modem-port speed by typing AT%G1%Bn (where n equals the
desired speed).
