Chapter 1: INTRODUCTION
1-6 CSMIM-T1 Hardware Installation Guide
Figure 1-1 CSMIM-T1 Front Panel
1.6.1 Console Port
The Console Port is used for system setup and diagnostic purposes only.
A single RJ45 connector is used to connect a VT terminal and access the
command set. After booting, the console port is inactive.
