Telco Connection Information
CSMIM-T1 Hardware Installation Guide 1-11
Table 1-1 Telco Configuration Information
1.8.2 Connecting the CSMIM-T1 to a Fractional T-1 Line
In a fractional T-1 setup, only a portion of the 24 timeslots or DS-0’s are
used. Some may be routed through the Drop and Insert Port to a PBX, as
in a voice application. Table 1-2 provides a short list of information
necessary to use a fractional T-1 circuit in a PPP environment.
Configurations may vary depending on the hub. The line configuration
information shown in Table 1-2 must be supplied by the service provider.
Table 1-2 Telco Configuration Information
For more instructions on the T-1 setup, please refer to the Annex Network
Administrator’s Guide for the CSMIM-T1.
Configuration Information
Required by User
Configuration Information
Supplied by
Service Provider
Line Coding B8ZS or AMI
Frame Type ESF or D4
Clock Source Loop Timing or Local Timing
Configuration Information
Required by User
Configuration Information
Supplied by
Service Provider
Line Coding B8ZS or AMI
Frame Type ESF or D4
Clock Source Loop Timing or Local Timing
DS-0’s (Timeslots)
Timeslots being used for each
end of the circuit
