Commands

CSMIM-T1 Hardware Installation Guide

7-21

Table 7-4

Modem Connections When %L1 or %L3 is Set

The following chart indicates the connections that the modem can
establish when %L4 is set. Both modems must support the V.8 protocol
when using %L4 or a connection will not be made.

NOTE

When both the originate and answer modems are V.8 modems,
setting 300 bps will make a V.21 connection.

Mode Setting on
Originating Modem

Mode Setting on Answer Modem

Bell212A Bell103

V.34 (2400-28,800)

V.22[a]

—

V.FC (14,400-28,800)

V.22

—

V.32bis (4800-14,400)

V.22[a]

—

V.32 (4800-9600)

V.22[a]

—

V.22bis (2400)

V.22[a]

—

V.22[a] (1200)

V.22[a]

—

V.22[b] (600)

—

—

Bell212A (1200)

Bell212A

Bell212A

Bell103 (300)

Bell103

Bell103
