Command Prefix: “R” and “W”. It consists of 16 items, 26 bytes (52 ASCII characters) as shown in Table 11.32.
Table 11.32. Block B for “R” or “W” Commands For the Rate Mode
ITEM (HEX)
SUFFIX
DESCRIPTION
Output offset
1, 2, 3
26 Output scale 4, 5, 6
25 Serial delay 7
24 Recognition character 8
23 Input offset 9, 10, 11
Input scale 12, 13, 14
21 Scale operator 15
20 Pulsed alarm number 16
1E Serial time 17, 18
1D Serial address 19
1C Bus format 20
1B Data format 21
1A Serial configuration 22
19 Baud rate 23
18 Gate rate 24
Pulsed alarm time
BYTE NO. &
ORDER
27
22
17 25, 26
This block for command prefixes P, G, R, W consists of 3 items, 11 bytes (22 ASCII characters) as shown in
Table 11.33.
ITEM (HEX)
SUFFIX
11.32.4 Block C For Batch Mode Only
Table 11.33. Block C for “P, G, R, W” Prefix Commands for the Batch Mode
DESCRIPTION BYTE NO. &
ORDER
2B Number of batches (raw) 1, 2, 3
2A Batch value (raw) 4, 5, 6, 7
29 Total (raw) 8, 9, 10, 11
11.32.5 Block D For Batch, Square-Root And Rate Modes
a) This block is for the “R” and “W” prefix commands and consists of 2 items, 6 bytes (12 ASCII characters) as
shown in Table 11.34.
Table 11.34. Block D For “R” and “W” Prefix Commands for the Batch, Square-root and Rate Modes.
ITEM (HEX)
SUFFIX
DESCRIPTION BYTE NO. &
ORDER
2D Unit of measure number 2 1, 2, 3
2E Unit of measure number 1 4, 5, 6
11.32.6 Block E For Batch, Square-Root And Rate Modes
This block is for the “P” and “W” prefix commands and consists of 5 items, 9 bytes (18 ASCII characters) as
shown in Table 11.34.
CF 125 INFINITY SC GUIDE 73 M1519/N/0605
