LOCKOUT FUNCTION CORRESPONDING ITEM
=1
Locked
L2C.8=0
=1 Unlocked
Locked FIL.CNF: Filter Configuration
L3 CNF: LOCKOUT CONFIGURATION #3
L3C.1=0
=1 Unlocked
Locked FIL TI: Filter Time Constant
L3C.2=0
=1 Unlocked
Locked SP CNF: Setpoints 1 and 2
Configuration
L3C.3=0
=1 Unlocked
Locked AL CNF: Alarms 1 & 2 (Setpoint 3 & 4
Configuration)
L3C.4=0
=1 Unlocked
Locked AL FNC: Alarms 1 & 2 functions
L3C.5=0
=1 Unlocked
Locked AL RDG: Number of readings for alarms
1 & 2 to be activated
L3C.6=0
=1 Unlocked
Locked SP DB and AL DB: Setpoints 1 & 2 and
Alarms 1 & 2 deadbands
L3C.7=0
=1 Unlocked
Locked OUT.CNF: Output Configuration
L3C.8=0
=1 Unlocked
Locked OT.SC.OF: Output scale and offset (2-
coordinate format)
L4 CNF: LOCKOUT CONFIGURATION #4
L4C.1=0
=1 Unlocked
Locked BAUD: Baud Rate Communication
L4C.2=0
=1 Unlocked
Locked SERCNF: Serial Communication
Configuration
L4C.3=0
=1 Unlocked
Locked ADDRES: Device address for RS-485
L4C.4=0
=1 Unlocked
Locked DAT FT and BUS FT: Data Format and
Bus Format
L4C.5=0
=1 Unlocked
Locked SERCNT: (Number of readings
between each printout)
L4C.6=0
=1 Unlocked
Locked CAL VZ, CAL VS, CALmAZ, CALmAS,
C.JUN.OF
10.2 Input Type (“Input”)
All four commands with the Command Suffix “05” use just two characters (two nibbles of data). The most-
significant nibble (MSN) gives the CLASS of input and the least-significant nibble (LSN) gives the selected
range or TYPE.
Table 10.2 Input Type
BIT NUMBER
7 6 5 4 INPUT CLASS
0 0 0 0 TC: Thermocouple
0 0 0 1 RTD: Resistance Temperature Detector
0 0 1 0 VOLT: DC Voltage
0 0 1 1 CURRNT: DC Current
- - - - Not Used
0 1 0 1 BRIDGE: Strain Gauge
0 1 1 0 POT: Potentiometer/Slide wire
- - - - Not Used
