Cooper Instruments & Systems DFI INFINITY Digital Force Indicator/Controller User Manual
Page 24
COMMAND SUFFIX ITEM
AFFECTED #
CHAR
SECTION
E
04
Set alarm mode
-
7.2.2
G,P,R,W
04
Setpoint 4 value
6
11.16
X
04
Read time value
8
8.2.3
Z
04
Reset LATCHED setpoints
-
8.2.3
E
05
Start (Batch mode only)
-
8.2.3
G,P,R,W
05
Setpoint 5 value
6
11.17
Z
05
Power On reset (Hard reset)
-
8.2.3
G,P,R,W
06
L1 CNF (Lockout byte 1)
2
11.1
G,P,R,W
07
L2 CNF (Lockout byte 2)
2
11.1
G,P,R,W
08
L3 CNF (Lockout byte 3)
2
11.1
R,W
09
MODE (operational mode)
2
11.2
G,P,R,W
0A
CONFG 1 (Configuration 1)
2
11.4
G,P,R,W
0B
CONFG 2 (Configuration 2)
2
11.5
G,P,R,W
0C
CONFG 3 (Configuration 3)
6
11.6
G,P,R,W
0D
CONFG 4 (Configuration 4)
2
11.7
G,P,R,W 0E AV.CNF
(Average
configuration only available
for rate or square-root rate)
2 11.8
G,P,R,W
11
Bat DP (Batch decimal point ) or
RTE DP (Rate decimal point)
2 11.13
G,P,R,W
12
B.LOAD (Batch load) or
RTE OF (Rate Offset)
6 11.14
G,P,R,W
13
BAT SC (Batch Scale) or
RTE SC (Rate Scale)
6 11.14
G,P,R,W
14
TOT DP (Total decimal point)
2
11.13
G,P,R,W
15
TOT OF (Total offset)
6
11.14
G,P,R,W
16
TOT SC (Total Scale)
6
11.14
G,P,R,W
17
AL TI (Alarm time)
4
11.11
G,P,R,W
18
GATE T (Gate time)
2
11.9
R,W 19
Baud
rate
2
11.22
R,W
1A
SER.CNF (Serial Communication Configuration) 2
11.23
G,P,R,W
1B
DAT FT (Communication Bus Format)
2
11.24
G,P,R,W
1C
BUS FT (Communications Bus Format)
2
11.25
G,P,R,W
1D
ADDRES (RS-485 device # address)
2
11.26
G,P,R,W
1E
SER TI (time between each transmission)
4
11.27
R,W
1F
SET TI (Set time)
6
11.18
G,P,R,W 20 Pulsed
setpoint
number
2
11.10
G,P,R,W 21 Scale
operator
2
11.15
G,P,R,W 22 Input
Scale
6
11.12
G,P,R,W 23 Input
Offset
6
11.12
G,P,R,W
24
Communication Recognition character
2
11.28
R,W
25
Communication Turnaround Delay
2
11.30
G,P,R,W 26 Output
scale
6
11.19
G,P,R,W 27 Output
Offset
6
11.20
G,P,R,W 28 Time
value
6
11.21
G,P,R,W
29
Total raw value
8
11.21
G,P,R,W
2A
Batch raw value (In Batch mode only)
8
11.21
G,P,R,W
2B
# of Batches raw value (In Batch mode only)
6
11.21
G,P,R,W
2C
Unit of measure #1
6
11.29
G,P,R,W
2D
Unit of measure #2
6
11.29
R,W
2E
Clock frequency calibration
2
11.31
R,W
2F
Analog out Volt zero calibration
4
11.31
R,W
30
Analog out Volt span calibration
4
11.31
R,W
31
Analog out current zero calibration
4
11.31
R,W
32
Analog out current span calibration
4
11.31
G,P 33
Display
mode
2
11.3
G,P,R,W
40
RAM or EEPROM Block A
Batch: 76 Rate
(SQ RT): 78
11.32
CF 125 INFINITY SC GUIDE
20
M1519/N/0605
