To write these values to RAM of meter #15, send the command *15P0C31C814. The meter will respond
with 15P0C.

11.7 Configuration 4 (“CNFG 4”)

This item is 1 byte (2 characters). It uses command prefixes G, P, R, and W with the suffix 0D. The bit pattern
is as follows:

Table 11.8. Configuration 4 (“CNFG 4”) Bits

FUNCTION

BIT
NO.


VALUE RATE AND SQ RT MODES

BATCH MODE

0 0

1

External Reset A triggered on pulse edge
External Reset A triggered on pulse level

1 0

1

Analog output=Voltage mode
Analog output=Current mode

2 0

1

Display hold Disabled
Display hold Enabled

3 0

1

External print request Disabled
External print request Enabled

10 ms output pulse on P2-15 at the
beginning of each RATE measurement

Pulse output on P2-15 low when input
rate cut off; high if rate not cut off

4 0


1

Pulse out period on P2-15 is programmable via “SER TI” (Refer to Section 11.27).
Pulses are low for 70 to 140 milliseconds

5 0

1

BCD decimal point is right justified (for desktop printer)
BCD decimal point is left justified (for specialty printer)

6 0

1

Front-panel reset Disabled
Front-panel reset Enabled

7 0


1

Input and Rate Scale and Offset
Disabled
Input and Rate Scale and Offset
Enabled


Front-panel STOP Disabled

Front-panel STOP Enabled


EXAMPLE: In Batch Mode, you want to trigger the external Reset A on the pulse edge, set the analog output to
Current, enable external hold and print request, set the output pulse period to 25 ms, make the BCD decimal
compatible with a desktop printer, and disable the front-panel STOP button.

These settings correspond to a binary value of 10011110=9E Hex.

To write these values to EEPROM of meter #15, send the command *15W0D9E. The meter will respond
with 15W0D.


11. 8 Average Configuration (“AVG.CNF”) For Rate And Square Root Rate Modes Only

This item pertains to Rate and Sq Rt Modes only. It is 1 byte (2 characters) and uses command prefixes G, P,
R, and W with the suffix 0E. The bit pattern is as follows:
