FUNCTION BIT
NO.
VALUE RATE AND SQ RT MODES
BATCH MODE
3 0
1
SP 4 is active above
SP 4 is active below
4 0
1
SP 5 is active above
SP 5 is active below
5 0
1
SP 3 action is not delayed
SP 3 action is delayed for 4
alarm readings Reset action is normal (manual)
At SP 3, meter auto resets to 0; or
at 0 resets to SP 3 (if Batch value
is count down).
6 0
1
SP 4 Action is not delayed
SP 4 action is delayed for 4
alarm readings BAT NO counts up
BAT NO counts down from SP 4 if
Bit No. 6 in CNFG 1 (Section
11.4) is set.
7 0
1
Meter is set for 60 Hz power
Meter is set for 50 Hz power
EXAMPLE: You want Setpoints 1, 2 and 3 to be active above, and Setpoints 4 and 5 to be active below. You
also want to used the auto reset action, have the BAT NO count down, and set the meter for 50 Hz.
These settings correspond to a binary value of 11111000 = F8 HEX.
To write these values to EEPROM of meter #15, send the command *15W0BF8. The meter will respond
with 15W0B.
11.6 Configuration 3 (“CNFG 3”)
This item is 3 bytes (6 characters). It uses command prefixes G, P, R, and W with the suffix 0C. The bit pattern
is as follows:
1) Most significant byte (Byte 3)
Table 11.5. Configuration 3 (“CNGF 3”)
FUNCTION BIT
NO.
VALUE RATE AND SQ RT MODES
BATCH MODE
0-3 0 Analog Output disabled Analog Output disabled
1 RATE is sent to analog output BATCH value is sent to analog output
2 AVG RT is sent to analog output BAT NO is sent to analog output
3 TOTAL is send to analog output TOTAL is send to analog output
4 Output is ramped (time proportional) Output is ramped (time proportional)
4-7 0 BCD output disabled BCD output disabled
1 RATE is send to BCD output BATCH value is sent to BCD output
2 AVG RT is sent to BCD output BAT NO is sent to BCD output
3 TOTAL is send to BCD output TOTAL is sent to BCD output
4 TIME is sent to BCD output TIME is sent to BCD output
b) Middle Byte (Byte 2)
