Cooper Instruments & Systems DFI INFINITY Digital Force Indicator/Controller - Manual (Page 71)

Table 11.21. Serial Configuration (“SER.CNF”) Bits
BIT NO. VALUE FUNCTION
0 0
1
1 Stop bit
2 Stop bits
1-2 0
1
2
3
No parity
Odd parity
Even parity
Not used
3 0
1
Chunk transmission*
Single, long transmission **
4-7 1 Not used
*Chunk transmission means that the meter transmits data while it is performing measurements.
**A single, long transmission means that all of the data is transmitted at the same time. The meter does not do
other tasks until transmission is complete. This mode is useful and fast only with higher baud rates such as
9600 and 19200. It is not recommended for lower rates.
11.24 Data Format (“DAT FT”)
This item is 1 byte (2 characters). Different bits of this byte specify the data to transmitted in response to
Continuous Communications (see Section 7), V01 and external print commands (See Section 8). This item
uses prefixes G, P, R, and W with the suffix 1B.
Table 11.22 shows bit assignments.
Table 11.22. Data Format (“DAT FT”) Bits
BIT NO. VALUE FUNCTION
0 0
1
Alarm status character excluded from transmission
Alarm status character included in transmission
1 0
1
BATCH (or RATE) value excluded from transmission
BATCH (or RATE) value included in transmission
2 0
1
BAT NO (or AVG RT) excluded from transmission
BAT NO (or AVG RT) included in transmission
3 0
1
TOTAL value excluded from transmission
TOTAL value included in transmission
4 0
1
TIME excluded from transmission
TIME included in transmission
5 0
1
No unit of measure for BATCH (or RATE)
Unit of measure transmitted for BATCH (or RATE)
6 0
1
No unit of measure for BAT NO (or AVG RT)
Unit of measure transmitted for BAT NO (or AVG RT)
7 0
1
No unit of measure for TOTAL value
Unit of measure transmitted for TOTAL value
EXAMPLE: You are in Rate Mode using continuous transmission. You want to configure RAM such that the
transmission includes the alarm status character, the RATE value and unit of measure, and the TOTAL value.
CF 125 INFINITY SC GUIDE 67 M1519/N/0605
