11.4 Configuration 1 (“CNFG 1”)
This item is 1 byte (2 characters). It uses command prefixes G, P, R, and W with the suffix 0A. The bit pattern
is as follows:
Table 11.3. Configuration 1 (“CNFG 1”) Bits
FUNCTION BIT
NO.
VALUE RATE AND SQ RT MODES
BATCH MODE
1
Our transistor 1 is on if SP 1 is active
Out transistor 1 is off if SP 1 is active
1
Our transistor 2 is on if SP 2 is active
Out transistor 2 is off if SP 2 is active
1
Our transistor 3 is on if SP 3 is active
Out transistor 3 is off if SP 3 is active
3 0
1
Our transistor 4 is on if SP 4 is active
Out transistor 4 is off if SP 4 is active
4 0
1
Our transistor 5 is on if SP 5 is active
Out transistor 5 is off if SP 5 is active
5 0
1
Display is set to full brightness
Display is set to 50% brightness
6 0
1
SP 3 is assigned to RATE
SP 3 is assigned to AVG RT
SP 4 is assigned to TOTAL
SP 4 is assigned to BAT NO
7 0
1
SP 4 is assigned to RATE
SP 4 is assigned to AVG RT BATCH value counts up
BATCH value counts down
0 0
1 0
2 0
EXAMPLE: In Rate Mode, you want Setpoints 1, 3, and 4 to be active high, and Setpoints 2 and 5 to be active
low. You also want the display to be set to full brightness, Setpoint 3 to be assigned to RATE, and Setpoint 4 to
be assigned to “AVT RT” (Average Rate).
These settings correspond to a binary value of 10010010=92 Hex.
To write these values to RAM of meter #15, send the command *15P0A92. The meter will respond with
15P0A.
11.5 Configuration 2 (“CNFG 2”)
This item is 1 byte (2 characters). It uses command prefixes G, P, R, and W with the suffix 0B. The bit pattern
is as follows:
Table 11.4. Configuration 2 (“CNFG 2”) Bits
FUNCTION BIT
NO.
VALUE RATE AND SQ RT MODES
BATCH MODE
0 0
1
SP 1 is active above
SP 1 is active below
1 0
1
SP 2 is active above
SP 2 is active below
2 0
1
SP 3 is active above
SP 3 is active below
