Table 11.6. Configuration 3 (“CNFG 3”), Byte 2
FUNCTION BIT
NO.
VALUE RATE AND SQ RT MODES
BATCH MODE
0-1 0 SP 1 output is normal (unlatched)
1 SP 1 output is latched
2 SP 1 output is pulsed
3 Not used
2-3 0 SP 2 output is normal (unlatched)
1 SP 2 output is latched
2 SP 2 output is pulsed
3 Not used
4-5 0 SP 3 output is normal (unlatched)
1 SP 3 output is latched
2 SP 3 output is pulsed
3 SP 3 output is hysteretic (Hysteresis=SP4-SP3) in Rate/Sq. Rt. Modes (Not
applicable in Batch Mode)
6-7 0 SP 4 output is normal (unlatched)
1 SP 4 output is latched
2 SP 4 output is pulsed
3 SP 4 output is hysteretic (Hysteresis=SP4-SP3) in Rate/Sq. Rt. Modes (Not
applicable in Batch Mode)
c) Least significant Byte (Byte 1)
Table 11.7. Configuration 3 (“CNFG 3”), Byte 1
FUNCTION BIT
NO. VALUE
RATE AND SQ RT MODES BATCH MODE
0-1 0 SP 5 output is normal (unlatched)
1 SP 5 output is latched
2 SP 5 output is pulsed
3 Not used
2-3 0 Cutoff frequency disabled: all rates counted
1 0 Hz cutoff: only positive rates counted
2 100 Hz (5 Hz Sq Rt): rates > 100 Hz (5 Hz SQ RT) counted
3 300 Hz (10 Hz Sq Rt): rates > 300 Hz (10 Hz SQ RT) counted
4-5 0 Meter waits 11 s for final pulse Fast SP #3 response 1-2 ms
1 Meter waits 2 s for final pulse Not Used
2 Meter waits 0.5 s for final pulse Not used
3 Meter waits 0.15 s for final pulse SP #3 normal response 10-20 ms
6-7 Not
used
Not used Not used
EXAMPLE: In Rate Mode, you want to output the RATE reading on analog output, the TOTAL reading on BCD
output, make Setpoints 1 and 5 unlatched, Setpoint 2 pulsed, Setpoint 3 latched, Setpoint 4 hysteretic, set the
time out (waiting time) to 2 s, and use a zero cutoff value.
These settings correspond to the following binary values:
Byte 1= 00110001 binary=14 Hex
Byte 2= 11011000 binary=C8 Hex
Byte 3= 00010100 binary=31 Hex
