COMMAND SUFFIX ITEM AFFECTED # CHAR SECTION
G,P 41 RAM Block B Batch and (SQ
RT): 34
Rate:36 11.32
R,W 41 EEPROM Block B Batch and (SQ
RT): 50
Rate: 52 11.32
42 RAM or EEPROM Block C (only for Batch
mode) 22 11.32
R,W 43 EEPROM Block D 12 11.32
R,W 44 EEPROM Block E 18 11.32
G,P,R,W
NOTES:
1. Each BLOCK is the string o HEX-ASCII data that is produced by the concatenation of the data for single
items listed below.
a) For BATCH mode:
Block A (for G,P,R,W commands)=
16+15+14+13+12+11+0D+0C+0B+0A+08+07+06+05+04+03+02+01
Block B (for G and P commands)=
25+24+23+22+21+20+1E+1D+1C+1B+17
Block B (for R and W commands):
27+26+25+24+23+22+21+20+1E+1D+1C+1B+1A+19+17
Block C (for G,P,R,W commands):
2B+2A+29
Block D (for R and W commands):
2D+2C
Block E (for R and W commands):
32+31+30+2F+2E
b) For Rate mode and Square-root mode:
Block A (for G,P,R,W commands):
16+15+14+13+12+11+0E+0D+0C+0B+0A+08+07+06+05+04+03+02+01
Block B (for G and P commands):
For rate mode:
25+24+23+22+21+20+1E+1D+1C+1B+18+17
For square-root mode:
27+26+25+24+23+22+21+20+1E+1D+1C+1B+1A+19+17
Block C:
Not available
Block D (for R and W commands):
2D+2C
Block E (R and W commands):
32+31+30+2F+2E
CF 125 INFINITY SC GUIDE 21 M1519/N/0605
