Table 10.3. Input Range for Thermocouple
BIT NUMBER
3 2 1 0 RANGE OR TYPE
0 0 0 0 J
0 0 0 1 K
1 0 1 0 T
0 0 1 1 E
0 1 0 0 N
0 1 0 1 DIN
J
0 1 1 0 R
0 1 1 1 S
1 0 0 0 B
Table 10.4 Input Range for RTD
BIT NUMBER
3 2 1 0 RANGE OR TYPE
0 0 0 0 2-wire, 0.003926 Alpha (NIST)
0 0 0 1 3-wire, 0.003926 Alpha (NIST)
0 0 1 0 4-wire, 0.003926 Alpha (NIST)
0 0 1 1 2-wire, 0.00385 Alpha (DIN)
0 1 0 0 3-wire, 0.00385 Alpha (DIN)
0 1 0 1 4-wire, 0.00385 Alpha (DIN)
0 1 1 0 Linear or Ohms
Table 10.5. Input Range or Type for VOLT
BIT NUMBER
3 2 1 0 INPUT RANGE CONDITION
If INP.3=
0 0 0 0 -10 to 110 mV 0
0 0 0 0 -60 to 60 mV 1
0 0 0 1 -0.1 to 11 V 0
0 0 0 1 -0.60 to 0.60 V 1
0 0 1 0 -1 to 11 V 0
0 0 1 0 -6 to 6.0 V 1
0 0 1 1 -10 to 110 V 0
0 0 1 1 -60 to 60 V 1
Input Range or Type for Current
BIT NUMBER
3 2 1 0 INPUT RANGE
0 0 0 0 0 to 20 mA
0 0 0 1 4 to 20 mA
NOTE: No Range or Type for Bridge or Pot.
EXAMPLE: The meter (#15 HEX, Recognition Character *) is to be placed on the 0-100 V range. The computer
writes to the EEPROM using MSN=2 and LSN=3 from the above table:
*15W0523.
The meter will echo the command if BUS.3=1.
NOTE: If P05 is exercised, then meter will SOFT RESET (RESET 1) after completing communication.
