10.25.1 BLOCK A
This block consists of ten (10) items and thirty bytes (60 ASCII characters) as Table 10.39:
Table 10.39. Block A
BYTE NO. & ORDER (HEX ITEM SUFFIX) DESCRIPTION
26
Analog Out Offset 1, 2, 3
17 Analog Out Scale 4, 5, 6
25 Input Offset 7, 8, 9
0B Input Scale 10, 11, 12
09 Display Offset 13, 14, 15
Display Scale 16, 17, 18
24 Setpoint 4 Value 19, 20, 21
23 Setpoint 3 Value 22, 23, 24
22 Setpoint 2 Value 25, 26, 27
21 Setpoint 1 Value 28, 29, 30
08
10.25.2 BLOCK B
This block consists of 17 items and 19 bytes (38 ASCII characters) as Table 10.40:
Table 10.40. Block B
(HEX ITEM SUFFIX) DESCRIPTION BYTE NO. & ORDER
1E Recognition Character 1
1F Units of Measure 2, 3, 4
20 Turnaround Delay 5
1A RS-485 device # 6
18 Communications Configuration 7
13 # readings delayed Alarms 8
12 Alarm function 9
11 Control Setpoints 3 and 4 10
10 Control Setpoints 1 and 2 11
15 Input type and range 12
0C DEC PT and CNT BY 13
16 Analog Out Configuration 18
07 Display Controls 15
1C Bus format 16
1B Data format 17
0E Filter Configuration 18
0A Input Configuration 19
10.25.3 BLOCK C
This block consists of 7 items and 10 bytes (20 ASCII characters) as Table 10.41:
Table 10.41. Block C
(HEX ITEM SUFFIX) DESCRIPTION BYTE NO. & ORDER
1D # of rdg Print Spac 1, 2
15 Alarm Hysteresis 3, 4
14 Setpoint Hysteresis 5, 6
04 Lockout Byte #4 7
03 Lockout Byte #3 8
02 Lockout Byte #2 9
01 Lockout Byte #1 10
