ADS Environmental Services Portable FlowShark Pulse QR 775006 A2 - Manual (Page 68)

Installation 3-31
Input/Output
Application
Cable Description
Analog Input 32.8-foot (10-m) connection cable, Portable FlowShark Pulse – analog
input (one end with connector for multifunctional port, other end with
open cable end)
Analog Output 32.8-foot (10-m) connection cable, Portable FlowShark Pulse – analog
output (one end with connector for multifunctional port, other end with
open cable end)
Digital Input 32.8-foot (10-m) connection cable, Portable FlowShark Pulse – digital
input (one end with connector for multifunctional port, other end with
open cable end)
Relay Output 32.8-foot (10-m) connection cable, Portable FlowShark Pulse – relay
output (one end with connector for multifunctional port, other end with
open cable end)
Cable types for connecting peripherals to the Portable FlowShark Pulse
Cable Connection Wire Color Function PIN Assignment
on Connector
Portable FlowShark Pulse
-> analog input gray
brown
0/4 – 20 mA
AGND
3
2
Portable FlowShark Pulse
-> analog output pink
brown
0 – 10 volts
GND
4
5
Portable FlowShark Pulse
-> digital input white
brown
DE active 3.3 volts
GND
6
5
Portable FlowShark Pulse
-> relay output green
brown
gray
Root contact (COM)
normally closed (NC)
normally open (NO)
8
7
1
Wiring pre-configured cables
